Nema34 Stepper Motor 116mm Dual Shaft 34HS4802B For CNC Router Milling Machine

Name: Nema34 Stepper Motor 116mm Dual Shaft 34HS4802B For CNC Router Milling Machine
Brand: Rattm Motor
Price: 46 USD

Brand Name : Rattm Motor

Model Number : 34HS4802B

Certification : CE CCC

Place of Origin : China

MOQ : 1piece

Price : $46-49.5

Payment Terms : T/T, Western Union,Paypal

Supply Ability : 5000

Delivery Time : 2-7 work days

Packaging Details : Independent anti-collision foam+outer box packaging for each product

Current : 5A

Number Of Phase : 2

Step Angel : 1.8°

Weight : 3.6 kg

Phase Inductance : 4.7mH

Body : 116mm

Shaft : Round Shaft 14mm Length

Shaft Diameter : 14 mm

Contact Now

Nema34 Stepper Motor 116mm Dual Shaft 34HS4802B 1230Oz-In 5.0A For CNC Router Milling Machine

Stepper motor's red wire connect to driver's A+ port
Stepper motor's green wire connect to driver's A- port
Stepper motor's yellow wire connect to driver's B+ port
Stepper motor's blue wire connect to driver's B- port

Model: 34HS4802B
Stepper Angle(°):1.8
Motor Length(mm):116mm
Rated Current(A):5
Phase Resistance(Ohm): 0.45
Phase Inductance(mH) : 4.7
Holding Torque(N.cm): 850
Detent Torque(N.cm) : 12.5
Rotor Inertia(g.cm2) : 1.8
Lead Wire number: 4
Motor Weight(g): 3600

Electrical Specification:

Nema34 Stepper Motor 116mm Dual Shaft 34HS4802B For CNC Router Milling Machine
